What are the classifications of elevators? Next, let the editor from the manufacturer of the air jet rice mill explain in detail. I hope this article can be helpful to everyone.

1、 HL type ring chain machine

The HL type circular chain centrifugal bucket elevator consists of a moving part (hopper and traction chain), an upper section with a transmission sprocket, a lower section with a tension wheel, an intermediate housing, a driving device, a reverse braking device, etc. The hopper of this elevator is arranged intermittently, using the "digging method" for loading and the "centrifugal feeding method" for unloading. The traction mechanism of this elevator consists of two circular chains.

Working principle of TH series bucket elevator: TH series bucket elevator is suitable for conveying powder, granular and small block materials without grinding or with low grinding properties. TH type is a circular chain bucket elevator that uses mixed or gravity unloading and digging loading. The traction component is made of high-quality alloy steel high circular chain. The central casing is divided into two forms: single channel and double channel. The internal heavy hammer box is automatically tensioned with constant force. The sprocket adopts a replaceable wheel rim combination structure. Long service life and easy replacement of wheel rims. The lower part adopts a gravity automatic tensioning device, which can maintain a constant tension force, avoid slipping or chain detachment. At the same time, the hopper has a certain tolerance when encountering jamming caused by accidental factors, which can effectively protect the lower shaft and other components. This bucket elevator is suitable for conveying powdery, granular, and small block shaped bottom grinding materials with a bulk density of less than 1.5t/m3 that are easy to remove. Such as coal, cement, gravel, sand, fertilizers, grains, etc. TH type bucket elevator is used for vertical conveying of various bulk materials. Suitable for conveying powdery, granular, and small block materials, with material temperatures below 250 ℃.

2、 NE series plate chain machine

The NE series plate chain bucket elevator is an inflow type feeding machine. The material flows into the hopper and is lifted to the top by the plate chain, and is discharged by itself under the gravity of the material. This series of elevators has multiple specifications (11 types from NE15 to NE800) and a wide lifting capacity; And with high production capacity and low energy consumption, it can gradually replace other types of elevators. Its main parameters are shown in the table below. This machine adopts a fully enclosed casing with low chain speed and almost no material return phenomenon, resulting in low reactive power loss, low noise, and long service life.

3、 DZC vibration machine

The DZC series motor vibration vertical hoist is composed of a lifting groove, a vibration motor, a vibration reduction system, and a base. This series of elevators uses a vibration motor as the vibration source. Two vibration motors of the same model, fixed on the lifting groove, are installed with their middle lines intersecting at a certain angle and rotating synchronously in opposite directions. The eccentric block carried by the vibration motor generates a centrifugal force component at various instantaneous positions during rotation, which moves back and forth along the throwing direction, causing the entire body supported on the shock absorber to vibrate continuously. The material is thrown up in the lifting groove while moving upward. After falling into the feeding groove, the material begins to be thrown up. At this time, the material can fully contact with the air and also play a role in heat dissipation and cooling. This elevator can vertically transport solid materials in powder, block, and short fiber forms (excluding those with viscosity and easy clumping), and can also complete the drying and cooling of materials. There are two types of structures: open and closed. And can be specially designed according to user needs

4、 Hydraulic press

Hydraulic hoist is a non scissor hydraulic lifting platform Suitable for the transportation of goods between two and three floors of industrial plants, restaurants, and eateries The lowest height of the countertop is 150-300mm, which is suitable for installation and use in workplaces where excavation of pits is not possible This platform does not require an upper lifting point and comes in various forms (single column, double column, four column). It runs smoothly, is easy and reliable to operate, and has economical and convenient transportation of goods between floors
